MAX LIGHT DESIGN

  • A window system with thermal insulation, featuring a smooth and slim profile line
  • The specific shape of the profiles (resembling steel profiles) gives the structure a modern industrial character
  • System application: fixed windows, opening windows: single- or double-sash windows with tilting, opened inwards
  • The Max Light DESIGN system is characterised by modern design
Technical Specification Description
Profile Thickness 74 mm
Glass Thickness 24 - 58 mm
Thermal Insulation (Uf) 1.0 - 1.5 W/m²K
Sound Insulation (Rw) up to 48 dB
Air Permeability Class 4 (EN 12207)
Water Tightness Class E1200 (EN 12208)
Wind Load Resistance Class C5 (EN 12210)
Burglar Resistance RC2
Operating Force Class 1 (EN 13115)
Maximum Sash Weight up to 200 kg
Available Configurations Single, Double, Triple, and Quad Track
Threshold Options Standard and Low Threshold
Color Options Various RAL colors and Woodgrain finishes
Hardware Compatibility Compatible with various hardware systems


MAX LIGHT DESIGN

ATRIBUTE

Max Light Design is an innovative and aesthetically pleasing window and door system offered by Aliplast Poland. This system combines modern design elements with excellent performance characteristics, making it an ideal choice for contemporary architectural projects.

With its sleek and minimalist profile, Max Light Design adds a touch of elegance to any building facade. The system features a profile thickness of 70 mm, which provides a balance between durability and slim sightlines, creating a seamless and visually appealing appearance.

One of the key highlights of Max Light Design is its exceptional thermal performance. The system offers impressive thermal insulation, with Uf values as low as 1.3 W/m²K, contributing to energy efficiency and reducing heat loss. This makes Max Light Design suitable for achieving sustainable and energy-conscious building designs.

In terms of versatility, Max Light Design offers various options for glazing thicknesses, ranging from 24 to 51 mm. This flexibility allows for the use of different types of glass, including double and triple glazing, to meet specific performance requirements and acoustic insulation needs.

Max Light Design prioritizes security and is designed to provide peace of mind. The system is compatible with high-quality hardware and locking mechanisms, ensuring reliable and effective protection against unauthorized access.

In addition to its functional aspects, Max Light Design offers customization options to suit individual preferences and design aesthetics. The system is available in a wide range of colors and finishes, including standard RAL colors and various decorative coatings. This allows architects and homeowners to achieve their desired visual impact and create harmonious building exteriors.

Max Light Design is also designed with ease of use in mind. The system offers smooth and effortless operation, allowing for comfortable opening and closing of windows and doors. This enhances the overall user experience and convenience.

Whether it’s for residential, commercial, or architectural projects, Max Light Design provides a perfect combination of style, functionality, and energy efficiency. Its modern design, coupled with outstanding performance characteristics, makes it a versatile and appealing choice for those seeking contemporary window and door solutions.
